PW-245
60W Single Output Industrial DIN Rail Power Supply
Description
Industrial 60W DIN rail power supply with universal input voltage range and regulated 24VDC output.
Designed for harsh environments with wide operating temperature range and high isolation protection. Installation must be carried out by qualified electricians.
Input & Output
- Universal input: 85-264VAC or 120-370VDC
- Output: +24VDC, 2.5A, 60W
- Single output industrial power supply
- Designed for DIN rail mounting
Protection & Compliance
- High I/O isolation test voltage up to 4000VAC
- Over-voltage class III
- Designed to meet EN61558-1 safety standards
- Output short circuit protection
- Over-current protection
- Over-voltage protection
Environmental
- Operating temperature: -40°C to +70°C (-40°F to +158°F)
- Storage temperature: -40°C to +85°C (-40°F to +185°F)
Key Features
- 60W Industrial DIN Rail PSU
- 24VDC Output, 2.5A
- 85-264VAC / 120-370VDC Input
- Wide Temperature Range
- 4000VAC Isolation
- Short Circuit & Overload Protection
Technical Specifications
Power Supply
| Input Voltage | 85VAC to 264VAC or 120VDC to 370VDC |
| Output Voltage | 24VDC |
| Output Current | 2.5A |
| Output Power | 60W |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
General
| Product Weight | 0.23 kg (8.04 oz) |
| Product Dimensions | 100 x 85 x 65 mm (3.9 x 3.3 x 2.5 in) |
| Packaged Weight | 0.27 kg (9.49 oz) |
| Packaged Dimensions | 133 x 90 x 64 mm (5.2 x 3.5 x 2.5 in) |
| GTIN (barcode) | 837324004755 |
